    3P Technik Rainwater Harvesting Kit C – Twin Filter System for Roofs up to 800m²

    The 3P Technik Rainwater Harvesting Kit C is the highest-specification filtration kit in the 3P Technik kit range, designed for large commercial, industrial, and agricultural rainwater harvesting installations serving roof catchment areas of up to 800m² per kit. The Kit C combines the 3P Technik Twin Filter — the most powerful filter in the 3P range — with a Calmed Inlet for sediment protection and an Overflow Siphon Uno for continuous surface-skimming and overflow management. Together, these three components deliver the first three steps of a professional-grade rainwater quality system.

    What Is Included in Harvesting Kit C

    • 3P Technik Twin Filter (1000650BR) — two-step self-cleaning rainwater filter for roof areas up to 800m². Supplied with stainless steel wall brackets. Installs in frost-free wall location or standard 1,000mm manhole chamber
    • Calmed Inlet (DN100 or DN125) — fitted to the tank inlet pipe, disperses incoming water at low velocity to prevent sediment disturbance and maintain dissolved oxygen levels
    • Overflow Siphon Uno — fitted at water surface level in the tank, continuously skims floating contaminants, surface oils, pollen, and debris to the overflow drain

    The Three-Step Cleaning Process

    Together, these three components address the most significant threats to stored rainwater quality: particulate contamination (Twin Filter), sediment disturbance (Calmed Inlet), and floating surface pollutants (Overflow Siphon Uno). The fourth step — floating intake on the distribution pump — is handled separately and is not included in this kit.

    Technical Specification

    • Maximum roof area: 800m² per kit (bypass configuration available for larger areas)
    • Twin Filter connections: DN100 or DN150 (4" or 6")
    • Twin Filter installation: frost-free wall or underground 1,000mm manhole chamber
    • Compatible with all standard PE, GRP, and concrete rainwater tanks

    Applications and Usage

    Harvesting Kit C is specified for large-scale rainwater harvesting projects where the highest filter capacity is essential. Typical applications include factory, warehouse, and logistics facility roofs; large agricultural buildings including grain stores, dairy units, and poultry barns; commercial car parks and hardstanding areas; and large commercial irrigation and washdown systems. The filtered rainwater collected is suitable for toilet flushing, industrial process water, vehicle washing, horticultural irrigation, and other non-potable uses. Kit C can be retrofitted into existing PE, GRP, or concrete tank installations and is compatible with all major UK rainwater tank manufacturers.

    Learn more about 3P Technik products here.
