GRAF Carat S 4800L In-Direct Rainwater Harvesting System

GRAF Carat S 4800L In-Direct Rainwater Harvesting System

GRAF 4800L Carat S In-Direct Rainwater Harvesting System for both household and outdoor use.

SKU: G70103

Enquire About Stock or Availability
GRAF Carat S 4800L In-Direct Rainwater Harvesting System (https://www.tankservices.co.uk/4800l-carat-s-in-direct-rainwater-harvesting-system)
Your Full Name*
Postcode For Delivery*
Your Phone Number*
Your Email Address*
Your Enquiry*
Got a Technical Question About This Product?
ㅤ
Description
GRAF Carat S 4800L In-Direct Rainwater Harvesting System
The GRAF Carat S 4800L In-Direct rainwater harvesting system captures rainwater from your roof, filters it and stores it in a durable underground tank, ready to be reused around the home and garden. A complete GRAF system can cut mains water use by up to 50%, lowering bills and easing pressure on the public supply. With 4800 litres of storage, this configuration suits family homes of 4 to 6 people served by a medium to large roof area.
In-Direct (header-tank) supply
Filtered rainwater is pumped up to a small header tank in the loft and then gravity-fed to WCs and appliances. Mains back-up is introduced at the header tank through a Type AA air gap, giving complete separation from the mains and full fluid-category compliance - the preferred approach for larger homes.
Why choose the GRAF Carat S tank
The GRAF Carat S is a high-strength round tank with a rib-reinforced body and a load-bearing telescopic dome, giving proven durability and flexible installation depth for domestic and light-commercial sites. The tank is moulded from lightweight, high-strength polypropylene, so it is easy to handle on site yet built to last. A telescopic dome shaft adjusts to suit your ground level and can be specified with pedestrian or vehicle-rated covers.
Key features
- 4800L underground storage capacity
- Reduces mains water consumption by up to 50%
- Lightweight, corrosion-resistant polypropylene tank
- Height-adjustable telescopic dome shaft
- Loft header tank with gravity-fed distribution
- Type AA air gap for full mains separation and backflow protection
- Ideal for larger properties and multi-outlet installations
- Quick installation on a gravel base with granular backfill
Applications and Usage
This system is well suited to domestic new-builds, self-builds and retrofit projects where reducing mains water use is a priority. Harvested rainwater is perfectly suited to WC flushing, washing machines, outdoor taps and garden irrigation - typically over half of a household's daily water demand. Specifying rainwater harvesting can also support SuDS objectives and planning requirements by attenuating roof run-off on site. Installation is straightforward: the tank is bedded on a gravel base and surrounded with granular backfill, avoiding the cost and effort of a concrete surround on most domestic sites.
Learn more about GRAF products here.
Guides & Specification Sheets
Delivery
There may be an additional charge for delivery of items outside UK mainland and offshore addresses; under these circumstances, please contact us for an updated quote on delivery before placing your order. Further payment may still be required for larger items – Please get in touch with us and we can arrange an updated invoice to reflect this. Your purchase with us will be held and stock allocated.
This includes Scotland, the Highlands and Islands, Northern Ireland, the Isle of Wight and the Isle of Man.
Postcodes including (but not limited to) DD, PH, IV, KW, HS, AB, PA, KA, ML, EH, KY, FK PO (PO – Isle of Wight) and G.
If access to the delivery address is restricted, please advise when placing the order. This will allow us to arrange for a suitably sized delivery vehicle. The customer is responsible for arranging for large items to be offloaded from the delivery vehicle at the customer’s premises. Please allow up to 10 working days for delivery.
Our suppliers arrange delivery at the source, so carriage charges may vary based on your postcode. We will happily provide you with a delivery quote; just call us on 01722 442446.
Next-Day Delivery is not Guaranteed – The order Cut-off for Qualifying next-day delivery addresses is 3pm. But please contact us as some orders can still be fulfilled after this time.
Returns Policy
In accordance with United Kingdom and European law, customers have an unconditional right to cancel an order for a full refund from Tank Services up to 14 days after the goods are received by you.
If a customer wishes to return an item and cancel an order with Tank Services, please contact us within the period outlined above to arrange for the goods to be returned at cost to you. It is not Tank Services’ responsibility to pay for the return of your goods (see T&Cs for more information ).
Please take care when ordering the correct product, as the cost of returning tanks and bulky goods can be expensive.
It is the customer’s responsibility to ensure that good care is taken of the goods whilst in their possession. Goods must be returned to Tank Services in a suitable resale condition and unused as determined by the Supplier. Please see our standard Terms & Conditions for further details.
For BUSINESS Customers & Bespoke items; any refund will be less an administration fee of 20% + VAT of the total order value.

SKU: G70103

GRAF Carat S 4800L In-Direct Rainwater Harvesting System

GRAF 4800L Carat S In-Direct Rainwater Harvesting System for both household and outdoor use.

£0.00

Earn0
reward points

Graf Lid

Qty

Add To Your Wishlist

length:

2280mm

width:

1985mm

height:

2770mm

capacity:

4800

weight:

200

brand:

Graf

graf lid:

Pedestrian Loading Lid, Vehicle Loading Lid
