5000 Litre Steel Bunded Diesel Tank – DIS.5000

Tank & Bund:

A 5000-litre heavy-duty steel bunded diesel tank dispenser is suitable for commercial applications. This high-security tank is well suited for the construction, plant and agricultural industry.

The fuel is stored in the primary or inner tank and the outer tank forms the required bund with capacity for 110% of the primary tank’s capacity which makes this tank suitable for both domestic and commercial installations. This tank is suitable for the storage of Derv (white diesel), Gas Oil (red diesel) and HVO. A bunded tank is a tank within a tank, the outer tank provides protection for the inner tank which therefore makes it harder for the inner tank to fail. However, in the unlikely event of the inner tank failing, the outer tank will provide secondary containment.

Compliance:

This tank is made in accordance with BS799 pt5

Specifications:

• 5000 litre (1100 galls) capacity
• Security cabinet – front mounted
• Lockable cabinet swing door (optional roller shutter door available)
• 2″ fill point inside cabinet, c/w lever ball valve, non return valve & drip tray
• 2″ tank to bund vent
• 2″ bund to atmosphere vent
• 1.5″ pump feed (inside cabinet)
• 2 no 1.5″ tank sockets (inside cabinet)
• 1 no 1.5″ bund socket
• Hydrostatic gauge
• Overfill alarm (battery powered)
• Powder fire extinguisher (pre-serviced)
• 15 litre spill kit
• Mounted on full width bearers
• 4 x lifting eyes (for lifting when empty)
• Internal tank bracing
• This tank is made in accordance with BS799pt5
• Material: Steel to BS EN 10025-2:2004 S275JR
• Outer tank forms the required bund, with capacity for 110% of the total liquid being stored.
• 10 year tank warranty

Finish:

• Surface preparation ST2. We then apply a Zinfos 340WS solvent borne high performance anti-corrosive one coat system, multi surface self-priming mid sheen topcoat (50% gloss). Applied to give a wet film thickness of 150 microns and dry film thickness of 75 microns.
• Main Tank – RAL 7015 Grey
• Door – RAL 2001 Orange
• Other colours can be requested

Equipment Options:

• Hydrostatic Gauge (to replace clock face gauge above)
• Manway Access Hatch
• Generator Feed & Return Sockets

Premium Pumps: (PIUSI Pumps)

• Semi Rotary Diesel Pump
• 50 LPM 230v Pump Kit
• 70 LPM 230v Pump Kit
• 100 LPM 230v Pump Kit
• 50 LPM 110v Pump Kit
• 75LPM 12v Pump Kit
• 75LPM 24v Pump Kit
• 75LPM/35LPM Dual Volt 24v/12v Pump Kit

Economy Pumps:

• 45 LPM 230v Pump Kit
• 75 LPM 230v Pump Kit
• 45Lpn 12v BP3000 Pump Kit
• 45Lpn 24v BP3000 Pump Kit

Electric Pump Kits, supplied with:

• 6m Hose, Water & Particle Filter (10micron), Auto Nozzle & Mechanical Flow Meter

Hand Pump Kits, supplied with:

• 4m Hose, Water & Particle Filter (10micron), Manual Nozzle

This tank can be paired with most fuel management systems available on the market, please contact one of our team to discuss your requirement in more detail

Warranty:

• Tank – 10 years
• Pumps & Components – 1 year

Please note: This tank is designed as a static tank and is not certified to be transported when full of fuel. It also should be situated on a non-combustible even and level terrain/surface.
